Lamination Pins & Bushings
1. Pins& Fixture Bushings used in lamination fixtures to align multilayers during lamination.
2. Special bushings available upon request.
3. Slot Bushings & Round Bushings
2. Special bushings available upon request.
3. Slot Bushings & Round Bushings
Lamination Pins & Bushings
Product Overview:
- Pins& Fixture Bushings used in lamination fixtures to align multilayers during lamination.
- Special bushings available upon request.
- Slot Bushings & Round Bushings
Product Specification:
|
Specification |
SKD-11 |
|||
|
Pins |
Bushings |
|||
|
Round |
Square |
Round |
Square |
|
|
Length (mm) |
19、25、32、35、38、44、51、57、63 |
19、25、32、35、38、44、51、57、63 |
9.532 |
9.532 |
|
Diameter tolerance (mm) |
-0.01/-0.005 |
-0.01/-0.005 |
-0.08/-0 |
-0.08/-0 |
|
Width tolerance (mm) |
/ |
-0.01/-0.005 |
/ |
+0.02/+0.025 |
|
Slot hole (mm) |
/ |
/ |
15.57 |
15.57 |
|
Hardness (HRC) |
60±2 |
60±2 |
60±2 |
60±2 |
|
Notes: |
Size and special treatments are customized available. |
|||
